600 Seater Huge Gala Tent with Luxury Roof Lining for Weddings and
Parties
Liri BT Series:
| Type | Span Width | Bay Distance | Eave Height | Ridge Height | Main Profile |
| BT | 10m/32.8' | 5m/16.4' | 3.88m | 5.53m | 204x120x4mm(4-channel) |
| BT | 12m/39.4' | 5m/16.4' | 3.88m | 5.83m | 204x120x4mm(4-channel) |
| BT | 15m/49.2' | 5m/16.4' | 3.88m | 6.3m | 204x120x4mm(4-channel) |
| BT | 20m/65.6' | 5m/16.4' | 3.88m | 7.1m | 204x120x4mm(4-channel) |
| BT | 21m/68.9' | 5m/16.4' | 3.88m | 7.25m | 204x120x4mm(4-channel) |
| BT | 25m/82' | 5m/16.4' | 3.88m | 7.88m | 204x120x4mm(4-channel) |
| The length can be extended by 5m bay such as
15m,20m,30m,40m...Customized size is available. |
Frame struss: hard pressed extruded aluminium 6061/T6(15HW) which can last more
than 20 years.
Fabric cover: high quality double PVC-coated polyester textile, 100% waterproof,
flame retardant to DIN4102 B1, M2, CFM, UV resistant, tear
resistant, self-cleaning ability, etc.
Connector: strong hot-dip galvanized steel
Allowed temperature condition: -30 degree Celsius~+70 degree Celsius
Wind load: max. 100km/h (can be reinforced)
Snow load: 75kg/sqm (snow can't stay if use big degree roof pitch design)
Easy to be assembled and dismantled, movable.
No pole inside, 100% available interior space.
Accessories:
Covers: colorful cover, transparent cover, inflatable roof cover
Windows: dome or square clear PVC windows, mesh window, glass window for
glass wall
Wooden Flooring System: VIP cassette flooring, simple cassette flooring
Doors: double-wing glass door, single-wing glass door, glass fire door,
aluminum door, rolling shutter(automatic or manual)
Wall: soft PVC fabric wall, glass wall, ABS hard wall, sandwich panel
wall, steel plate wall
Fixing Methods: ground anchors, weight plate, expandable bolts
Rain Gutters: inner roof beam rain gutter or rain gutter between two similar
tents
Optional Items: table, chair, lighting, AC, carpet, installation tools, booth,
mobile toilet, etc.
Applications:
Widely used for parties, weddings, events, celebrations, sports,
trade shows, warehouse, Hajj, conferences, cafe shops, restaurants,
corporate events, etc.
Fixing Methods:
If it is concrete ground, pls use the expandable bolts.
If it is tarmac ground or grass ground, sand ground or other soft
grounds, pls use the steel anchors;
If it is plates system.
If you will make the concrete bases to fix the tent, pls use the
embeded bolts M24x500mm.
marble or tile ground or other kind indestructible grounds, pls use
the weight
Packaging of wedding tent hall:
aluminum frame packed in membrane film
hardware packed in solid carton box
roof and sidewall in professional PVC carry bag
Liri Tent series:
Tent Roof Type | Span Width | Bay Distance | Eave Height |
| "A" Shape | 3m~60m | 3m/5m | 2.6m/3m/3.3m/3.88m/4.2m/5m/5.2m |
| Domelike | 3m~40m | 3m/5m | 2.6m/3m/3.23m/3.88m/3.92m |
| High Peak | 3m~10m | 3m/4m/5m/6m/8m/10m | 2.5m/2.6m |
| Curve Shape | 15m~40m | 5m | 3.87m/3.89m |
| Polygon | 10m~60m | 5m | 4m |
| Cube Structure | 10m~30m | 5m | 5m |
