White Marquee Canopy Tent For 500 People Conference With Glass
Walls
Applications:
A shape Tent is very suitable for the temporary conference , party
, event , exhibition , church , wedding and so on , it take less
time for the installation and also easy to dismantle , cost saving
and environmentle friendly.
It is very popular for the outdoor temporary purpose, using different decoration
Dimension | Clear Span | Eave Height | Ridge Height | Bay Distance |
BT 15 | 15m | 4m | 6.3m | 5m |
BT20 | 20m | 4m | 7.2m | 5m |
BT25 | 25m | 4m | 7.88m | 5m |
Length | No limitation | |||
Main Profile | 204*120*4m |
The length for the structure is no limitation, it could increase or decrease in every 5m. The height could be also customize based on the exact need.
Optional Accessories
Packing:
1. Aluminum frame packed in membrane film
2. Hardware packed in solid carton box
3. Roof and sidewall in professional PVC carry bag
4. Customized packing is available
5 . Wooden cases is available for the glass and also the storage cage is optional.
6. Transportation rack is workable for the glass and doors
Structure
Framework: hard pressed extruded aluminum 6061/T6(15HW) which can
last more than 20 years.
Fabric Cover: high quality double PVC-coated polyester textile,
100% waterproof, flame retardant to DIN4102 B1, M2, CFM, UV
resistant, tear resistant, self-cleaning ability, etc.
Connector: strong hot-dip galvanized steel
Allowed Temperature Condition: -30 degree Celsius~+70 degree
Celsius
Wind Loading: max. 100km/h (can be reinforced)
Snow Loading: 30kg/sqm (snow can't stay if use big degree roof
pitch design)
Easy to be assembled and dismantled, movable.
No pole inside, 100% available interior space.
Sidewalls:Steel sandwich panels
Life Span
The modular design aluminum clear span tent , it could use for both permanent and temporary .
The frame could use for around 20- 25 years and the fabric could use for 8- 10 years.
![]() |
