Outdoor Wedding Canopy Tent Heavy Duty Gazebo Gazebo Marquees
Description
The large size of Gazebo Tent with the side height of 2.5m is
available in 6x6m, 8x8m, and 10x10m. All the framework and
junctions are made out of aluminum alloy. It is easy to assemble
the roofs because it uses eyelets and sliding plastic resin balls
to fix it. The optional accessories for the Gazebo tent include
clear windows, lining, weight plate, rain gutter, digital printing,
etc.
Gazebo Tents can be used as a single unit or combined by a rain
gutter to make a larger space and a special structure style.
Specification
| Gazebo Hotel Tent |
| Model | Width | Length | Side height | Ridge height |
| GAZ3 | 3m | 3m | 2.50m | 3.88m |
| GAZ4 | 4m | 4m | 2.50m | 4.28m |
| GAZ5 | 5m | 5m | 2.50m | 4.70m |
| GAZ6 | 6m | 6m | 2.50m | 5.10m |
Framework: hard pressed extruded aluminum 6061/T6(15HW) which can last more
than 20 years.
Fabric Cover: high quality double PVC-coated polyester textile, 100% waterproof,
flame retardant to DIN4102 B1, M2, CFM, UV resistant, tear
resistant, self-cleaning ability, etc.
Connector: strong hot-dip galvanized steel
Allowed Temperature Condition: -30 degree Celsius~+70 degree Celsius
Wind Loading: max. 100km/h (can be reinforced)
Snow Loading: 30kg/sqm (snow can't stay if use big degree roof pitch design)
Easy to be assembled and dismantled, movable. No pole inside, 100%
available interior space.
Fixing Methods
Applications
Used for parties, weddings, events, celebrations, sports, trade
shows, warehouse, Hajj, conferences, cafe, dinning room, hotel,
events, etc.
Accessories:
Covers: colorful cover, transparent cover, inflatable roof cover
Windows: dome or square clear PVC windows, mesh window, glass window for
glass wall
Wooden Flooring System: cassette flooring system
Doors: single-wing glass door, glass fire door, aluminum door, rolling
shutter(automatic or manual)
Wall: soft PVC fabric wall, glass wall, ABS hard wall.
Fixing Methods: ground anchors, expandable bolts and weight plate.
Rain Gutters: inner roof beam rain gutter or rain gutter between two similar
tents
