Brand Name : | LIRI TENT |
Model Number : | THx70m/400 |
Certification : | ISO9001:2008, SGS, TUV, CFM, IFAI, etc. |
Price : | Negotiable |
Payment Terms : | Western Union, L/C, T/T |
Supply Ability : | 100,000sqm/month |
Delivery Time : | within 20 days |
40M Clear Span Width Aluminum Alloy Exhibition Tent For Black Tea Exhibition
40x70m outdoor exhibition tent with plain white PVC sidewalls, it's easy to assemble and dismantle.
Applications:
It can be used for luxury events, exhibitions, shows, parties, etc Based on the multifunctional purpose, people just need to change the different decorations will be ok. For such a big tent, it can help you to save a lot of cost on the building, and it can also use for temporary purposes.
Tent Serie | Clearspan width | Length | Side height | Ridge height | Bay distance | Main profile size |
TH | 25m | without limit | 4m | 7.88m | 5m | 300x120x5mm |
TH | 30m | without limit | 4m | 8.8m | 5m | 300x120x5mm |
TH | 40m | without limit | 4m | 10.4m | 5m | 300x120x5mm |
TH | 50m | without limit | 4m | 12m | 5m | 300x120x5mm |
For the structure of the tent, it is strong enough for permanent or semi-permanent. The frame is using the 6061/ T6 aluminum frame, and it can use for about 20-25 years. For cover which is double-coated PVC, fire-retardant, waterproof, anti-UV, can be used under 65 degree, 10 years lifespan.
Features&Specifications
1.1 Framework material: Hard pressed extruded aluminum 6061/ T6
(13HW)
1.2 Connecter: Strong hot-DIP galvanized steel, zinc thickness over
80um
1.3 Cover material
A) High quality double PVC-coated polyester textile
B) 100% waterproof, flame retardant to DIN4102 B1, M2, CFM, UV
resistant, tear-resistant, self-cleaning ability, etc.
C) Fabric weight: From 750 to 900G/M2
Allowed temperature condition: -30 degree Celsius~+70 degree
Celsius
1.4 Wind load: Max. 100km/h (can be reinforced)
1.5 Snow load: 75kg/sqm (snow can't stay if use big degree roof
design)
1.6 Easy to be assembled and dismantled, removable
1.7 No pole inside, 100% room is available
1.8 Sizes can be customized(like side/leg height)
Tent Fixing Methods
Usage
1. Various exhibitions
2. Luxury events
3. Shows
.....
Optional Accessories
Packaging:
![]() |
